Ampere Heat –Astro Series See Through Front View Built In Linear Fireplaces
28 in stock
$2,380.00 $2,530.00
28 in stock
Compare| Astro Series Key Features | |
| See through linear electric fireplace | |
| Hidden venting bulit in | |
| All season usage: flames operate with or without heat output | |
| Main Dimensions | |
| Depth with front glass | 9.2″ |
| Back Firebox depth | 8″ |
| Front Width | 50″/ 60″/ 72″ |
| Front Height | 20.8″ for 50″/ 60″/ 72″ |
| Ember bed depth | 3″ |
| View area height | 13 1/2 ” for 50″/ 60″/ 72″ |
| View area width | 43.75″/ 53.75″/ 65.75″ |
| PRODUCT DIMENSIONS | |||||||
| Model# | A | B | C | D | E | F | G |
| SS36FV3FBL | 36” | 20” | 4.2” | 18.8” | 30.10”’ | 9.72” | 26” |
| SS42FV3FBL | 42” | 20” | 4.2” | 18.8” | 36.10” | 9.72” | 31.97” |
| SS50FV3FBL | 50” | 20” | 4.2” | 18.8” | 44.10” | 9.72” | 39.72” |
| SS60FV3FBL | 60” | 20” | 4.2” | 18.8” | 54.10” | 9.72” | 50” |
| SS72FV3FBL | 72” | 23.25” | 4.2” | 20.27” | 66.10” | 10.24” | 60” |
| SS84FV3FBL | 84” | 23.25” | 4.2” | 20.27” | 77.10” | 10.24” | 72” |
| Fireplace Type: | See- Through |
| Available Models: | 50, 60, 72 |
| Depth: | 9.2” including the front glass
8” firebox |
SPECIFICATIONS
| Technical Specification | |
| Product Finish | Black |
| Wattage | 1500W |
| Voltage | 120V |
| BTU | 5000 |
| Product Depth | 9.2″ |
| Product Height | 20.8″ |
| Product Weight | 104.12 |
| Timer | 1 |
| Remote Control | Yes |
| Built-in Thermostat |
Yes |
| Automatic Shut-off | Yes |
| Power Souce | Electric |
INSTALLATION
Easy-to-use builder’s brackets provided for 3 install options:
1.Wall Mounted: Use with backlights
2.Partial Recess:1″gap for flexible use
3.Full Recess:Flush to wall
| INSTALLATION | |
| YES | Recess Wall Mount only 0.2′ from the wall |
| YES | Wall hanging |
| Built in Clean face | |
| ELECTRICAL | |
| Heater | |
| 1500W/5000BTU | |
| Up to 10,000BTU’s &3,000 Watts | |
| Heater wire option | |
| Yes | |
| Plug in | |
| Yes |
Easy-to-use builder’s brackets provided for 3 install options:
1. Wall Mounted: Use with backlights
2.Partial Recess:1″gap for flexible use
3.Full Recess:Flush to wall
| Item# | A | B |
| SS36FV3f8L | 19.3” | 32.60” |
| SS42FV3f8L | 19.3” | 38.60” |
| SS50FV3f8L | 19.3” | 46.60” |
| SS60FV3f8L | 19.3” | 56.60” |
| SS72FV3f8L | 21.27” | 68.60” |
| SS84FV3f8L | 21.27” | 79.60” |
