Ampere Heat –Skyline Slim Series Contemporary Front Venting In Linear Fireplaces
28 in stock
$2,380.00 $2,530.00
28 in stock
Compare| Skyline Deep Box Series Key Features | |
| Super deep front venting linear electirc fireplaecs | |
| Contemporary style easy installation | |
| Front venting push in style super deep ember linear electric firplace | |
| All season usage: flames operate with or without heat output | |
| Main Dimensions | |
| Depth with front glass | 6.5″ |
| Back Firebox depth | 4″ |
| Back Firebox width | 52.4″/ 62.4″/ 74.4″/ 90.4″ |
| Back Firebox height | 16″ |
| Front Width | 50″/60″/72″/88″ |
| Front Height | 18.3″ for 50″/60″/72″/88″ |
| Ember bed depth | 3 1/5″ |
| View area height | 11 4/5″ for 50″/60″/72″/88″ |
| View area width | 50″/60″/72″/88″ |
| PRODUCT DIMENSIONS | ||||||||
| Model# | A | B | C | C1 | D | E | F | G |
| SS50FV3FBL | 55” | 18.3″ | 6.5” | 6” | 50” | 8.45” | 22.5” | 2.33″ |
| SS60FV3FBL | 65” | 18.3″ | 6.5”’ | 6”’ | 60” | 8.45” | 22.5” | 2.33″ |
| SS72FV3FBL | 77” | 18.3″ | 6.5” | 6” | 72” | 8.45” | 22.5” | 2.33″ |
| SS88FV3FBL | 93” | 18.3″ | 6.5” | 6” | 88” | 8.45” | 22.5” | 2.33″ |
| Fireplace Type: | Push-in |
| Available Models: | 50, 60, 72, 88 |
| Depth: | 4.2” including the front glass
4” firebox |
SPECIFICATIONS
| Technical Specification | |
| Product Finish | Black |
| Wattage | 1500W |
| Voltage | 120V |
| BTU | 5000 |
| Product Depth | 6.5″ |
| Product Height | 18.3″ |
| Product Weight | 104.12 |
| Timer | 1 |
| Remote Control | Yes |
| Built-in Thermostat |
Yes |
| Automatic Shut-off | Yes |
| Power Souce | Electric |
INSTALLATION
Easy-to-use builder’s brackets provided for 3 install options:
1.Wall Mounted
2.Full Recess:Flush to wall
| INSTALLATION | |
| YES | Recess Wall Mount only 0.2′ from the wall |
| YES | Wall hanging |
| ELECTRICAL | |
| Heater | |
| 1500W/5000BTU | |
| Up to 10,000BTU’s &3,000 Watts | |
| Heater wire option | |
| Yes | |
| Plug in | |
| Yes |
LOCATED THE FIREPLACE:
Due to the many different materials used on different walls, it is highly recommended that consult a local builder before install this appliance on the wall.
Select a location that is not prone to mositure and is located at least 36″ away from conbustible materisals such as curtain drapes, furniture, bedding, paper, etc.
| Item# | A1 | B1 | CC |
| SS50FV3f8L | 53.4” | 17” | 6.5” |
| SS60FV3f8L | 63.4” | 17” | 6.5” |
| SS72FV3f8L | 75.4.” | 17” | 6.5” |
| SS88FV3f8L | 91.4” | 17” | 6.5” |
